Take on steep climbs and hit technical descents with the best alloy trail wheel we''''ve ever made. The new Crossmax XL S is lighter and stronger, making tubeless setup a piece of cake.

Weight: 1790 grams (Pair 29")

Weight: 830 grams (Front 29")

Weight: 960 grams (Rear 29")

You never know what the trail may have in store for you: steep ascents and adrenaline-pumping descents, slightly muddy runs, and rugged boulders. Regardless of the characteristics of the trail and the fun it brings, the new Crossmax XL S is ready to roll. This best-in-class 29" alloy wheel features many of the proven technologies that have made Mavic a leader in MTB wheel innovation.

The rims are designed with our patented Fore technology, with a fully sealed top rim rim that does not require the use of rim tape. This saves 30 grams per wheel and avoids the difficulties of using rim tape to mount tubeless tires. We use ISM rim machining, which removes material in strategic areas of the rim to minimize weight without compromising strength. The rim features a 30mm internal width, optimized to squeeze the best performance out of any modern trail tyre, and our Black Shield technology gives them a distinctive finish that protects against scratches and abrasions.

We used 24 straight pull spokes to further fine-tune the ideal mix of lateral stiffness and vertical compliance. Infinity hubs feature a stiffer, lighter construction enhanced by the ultra-reliable ID 360 dual ratchet system for fast engagement. The wheelset is configured for Center Lock or 6-bolt disc mounts and is compatible with Shimano HG9, SRAM XD and Micro Spline freewheel freehubs. It is available in 29" only and is supplied with UST Tubeless valves, spare spokes and accessories.

MAIN FEATURES

Best-in-class alloy trail wheelset

Super strong ISM machined rim minimizes weight without compromising strength.

Increased confidence and control on bumpy trails

The 30mm wide rim is optimized for lower tire pressure, giving you a smoother ride with more traction and control. The triangular shape of the rim absorbs hard impacts so you can launch yourself down the descents.

The easiest tubeless system to use

Fore''''s fully sealed rimless rim technology makes tubeless tires easy to mount and change. The top rim of the rim remains intact, increasing the rim''''s stiffness and durability.

Specifications

Rims

Material: Maxtal

Material: S6000 Aluminum

Lightening: ISM

Tire: UST Tubeless and tubed

Inner width: 30mm

Black Shield treatment (protects your rim against impacts and scratches)

ETRTO size 29": 622x30TC

Asymmetric rim design

Fore tubeless technology without rim tape

SUP welded joint technology

SPOKES

Material: Steel

Nipples: Fore integrated in aluminum

Quantity: 24 front and rear

Lacing: double crossed front and rear, non-contact

cubes

Hub available with 6-bolt or center lock (R) brake rotors

Trucks: Front 15x110 Boost; Rear 12x148 Boost

Infinity Hubs

Instant Drive 360 freewheel technology

QRM Auto automatic bearing preload technology

versions

Disc fixing standard: six bolts or Center Lock®

Hub Width - Boost Only (110 Front, 148 Rear)

Free wheel; SRAM XD, Shimano HG, Shimano Micro Spline

COMPATIBILITY

Freewheel: Shimano HG9, XD or Micro Spline

Rear Axle: 12x148 Boost Thru Axle

Front Axle: 15x110 Boost Thru Axle

Freewheel bodies and adapters

Boost - Tightening Caps (LV2374400)

Shimano ID360 Alloy Freewheel Freehub Body (LV3780100)

Shimano Micro Spline ID360 Alloy Freewheel Freehub Body (LV3990100)

Freehub Body XD ID360 (LV3740100)

USE

ASTM CATEGORY 4: ENDURO AND TRAIL

For a longer wheel life, Mavic recommends that the total weight supported by the wheels does not exceed 120kg, bike includedSize

recommended tire years: 60 to 76 mm (2.35" to 3.0")

Delivered with

UST valve and accessories

Multifunction adjustment wrench

2 spare spokes with each wheel

Fore Adjustment Wrench

USO RECOMENDADO: MTB
