ESJOT Fine gear transmission pinion 14T 428 Ø20/22 726.00.50

ESJOT gear designed specifically for high OEM requirements and among the world's best sprockets on the market.

A special steel, high-quality hardening and optimum gearing guarantee extremely high strength and durability - ideal for high-wear conditions in all areas

- Steel 16 MnCR 5

- Worked on CNC lathes

- Hardening of 700 HV 40 for a depth of 0.4 mm

- Modern broaching guarantees an exact fit size on the motor shaft

- Radial and axial runout tolerance of less than 0.1mm

- 100% Made in Germany

- OEM quality
DIVISION: 428
CENTRAL FIXATION: FINE GEAR
INSIDE DIAMETER MIN.: 20 MM
MAX INTERNAL DIAMETER: 22 MM
INNER GEAR (QUANTITY OF TEETH): 20
QUANTITY OF HOLES: WITHOUT HOLE
VERSION: STANDARD
QTY TEETH: 14


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Generic TR 125 SM ie 15 CV, 11 kw 1cil. - Bastidores: --- 2012-2013
KSR-Moto TR 125 SM CBS 13,6 CV, 10 kw 1cil. - Bastidores: --- 2020-2021
KSR-Moto TR 125 SM ie 15 CV, 11 kw 1cil. - Bastidores: --- 2013-2016
KSR-Moto TR 125 SM ie CBS 13,6 CV, 10 kw 1cil. - Bastidores: --- 2018
KSR-Moto TR 125 SM ie CBS 15 CV, 11 kw 1cil. - Bastidores: --- 2017
KSR-Moto TR 125 X CBS 13,6 CV, 10 kw 1cil. - Bastidores: --- 2020-2021
KSR-Moto TR 125 X ie CBS 15 CV, 11 kw 1cil. - Bastidores: --- 2017
