Changeover relay 5 poles with support 12V 40A 108.02.70

HELLA shunt relay 5-pole, 12 V

Mini Relay with bracket

Closes the circuit between the power source and an electrical load

Application: headlights, additional lights, horns, heaters, fans, motors and power windows, air conditioning and ignition systems, etc.

Specs:

Inductive load: 15 A

capacitive load: 5 A

Rated current: 40A

Resistive load: 40 A

Voltage: 12 V

Temperature range: -40 ° C

Temperature range up to 125 ° C
VOLTAGE: 12V
QUANTITY TERMINALS: 5
SWITCH FUNCTION: SHIFT
LOAD CAPACITY: 40A
WITH STAND: YES
