Bosch multifunction relay, 12 V

Battterierelais / battery disconnect relay holder (fixed lugs)

Protects the starter battery against discharge

To separate an additional second battery from the starter battery when the alternator (generator) outputs free of charge

With reverse polarity protection and suppressor diode for suppression of inductive voltage spikes

sea water managed

power relay with screw and flat plug.

specs

Operating voltage: 8 - 14.5 volts

Switching power at 12 V: 75 A (250 A for short-term load = 1 s)

Temperature range: -40 to +100 °C

Contact: Simple contact

Mounting: 2 holes Ø 5.3 mm

Dimensions (LxWxH): 75 x 35 x 55mm
VOLTAGE: 12V
QUANTITY TERMINALS: 4
SWITCH FUNCTION: CLOSE
LOAD CAPACITY: 75A
WITH STAND: YES
