HELLA Relay MQ 1080031 108.20.07

HELLA shunt relay 4-pole, 12 V

Mini Relay with support and flat terminals and without fuse

An open relay the circuit between the power source and an electrical load is closed, that is, the device is on

relay operated via switches, encoders or control devices

Application: headlights, additional lights, horns, heaters, fans, motors and power windows, air conditioning and ignition systems, etc.

specs

Temperature range, max:. 80°C

Endurance (at 80°C) of normally open contact

Resistive load: 30 A

Inductive load: 16 A

capacitive load: 16 A
VOLTAGE: 12V
QUANTITY TERMINALS: 4
SWITCH FUNCTION: CLOSE
LOAD CAPACITY: 30A
WITH STAND: YES
