HELLA multifunctional relay 108.06.00

HELLA shunt relay 4-pole, 12 V

Micro relay without bracket

With resistance in parallel to the coil

An open relay the circuit between the power source and an electrical load is closed, that is, the device is on

relay operated via switches, encoders or control devices

Application: headlights, additional lights, horns, heaters, fans, motors and power windows, air conditioning and ignition systems, etc.

Specs:

Termination: 2 flat connectors 6.3 mm (terminals 3 and 5) 4.8 mm and 2 connections

Plug Type ID: C

Diagram: S2

Protection: IP5K4

Temperature range: -40 to +125 °C

Contact resistance (at 80 ° C), normally closed / normally open

Resistive load: - / 20 A

Inductive load: - / 20 A

capacitive load: - / 20 A
VOLTAGE: 12V
QUANTITY TERMINALS: 4
SWITCH FUNCTION: CLOSE
LOAD CAPACITY: 20A
WITH SUPPORT: YES
