OSRAM lamps are subjected to strict IEC 60810 NBR tests to guarantee their quality and efficiency. They are subjected to simulated background noise, with frequencies from 20 to 1050Hz, as well as ground vibrations, from 80 to 1000Hz. The result of both is summarized in lamps with their special vibration.
OSRAM's high-performance motorcycle lights provide much more illumination on the road than standard motorcycle lights. Its main features include whiter light and higher brightness, which provides better visibility on the road.
electrical data
Power input 68 W 1)
Rated Power 55.0W
Rated voltage 12.0V
Test voltage 13.2 V
1) Maximum
Photometric Data
Color temperature 3400K
Luminous flux 1550lm
Luminous flux tolerance ±15%
Dimensions and weight
Length 67.5mm
diameter 9mm
Product weight 7.00 g
Lifespan
Duration B3 150 h
Lifetime Tc 300 h
Additional product data
Bushing (standard designation) P14.5s
Certificates & Rules
ECE Category H1
APPLICATIONS OF THIS PRODUCT: According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
DUCATI 696 MONSTER 696 2009-2013
DUCATI 696 MONSTER ABS 696 2009-2013
DUCATI 916 S2 916 1998-2003
KAWASAKI NINJA ZX-7 RR (ZX750N) 750 1996-1997
KAWASAKI NINJA ZX-9 R (ZX900B) 900 1994-1997
KAWASAKI ZXR 750 (ZX750H) 750 1989-1990
KAWASAKI ZXR 750 (ZX750J) 750 1991-1992
KAWASAKI ZXR 750 (ZX750L) 750 1993-1995
SUZUKI GSX 600 F 600 1998-2001
SUZUKI GSX-R 1100 1100 1986-1988
SUZUKI GSX-R 1100 W 1100 1993-1997
SUZUKI GSX-R 600 600 1997-2000
SUZUKI GSX-R 750 750 1988-1991
SUZUKI GSX-R 750 750 1996-1999
SUZUKI GSX-R 750 W 750 1992-1995
SUZUKI SV 650 650 2001-2002
SUZUKI SV 650 S 650 1999-2002
SUZUKI TL 1000 R 1000 1998-1999
SUZUKI TL 1000 S 1000 1997-2000
