HIGHSIDER spotlight LED RENO TYP 4 1108708001

Oval headlight for lateral mounting. Thanks to its puristic, timeless design and innovative technology, it is a highlight for many motorcycles.

The chrome-plated reflector with clear glass also has a high beam, low beam, parking and daytime running light function. The daytime running light and position light are mounted in a central strip, so that a very beautiful optical image is created - the dipped beam lights up above the strip, the main beam light correspondingly below. The reflector emits an asymmetrical luminous flux - only approved for right-hand traffic -, E-examined.

Our highlights give your bike an unmistakable style! The unusual design and the perfect technology of the HIGHSIDER headlight series make it a highlight in any case!

Dimensions:

housing diameter: 200mm

Height insert diameter: 178 mm

housing depth: 160 mm

Distance between mounting holes (middle - middle): 170 mm

Distance between mounting hole (center) and end of case: approx. 90mm

Fixing: side with M8 threaded screws

Connections:

Black wire = ground (-)

Blue wire = low beam (+), power consumption at 12V: 1.8A, 22W

Yellow cable = high beam (+), power consumption at12V: 1.3A, 13W

Black wire = ground (-)

TFL:

Black wire = ground (-)

Red cable = daylight (+), consumption at 12V: 1.2A, 14W

White cable = position light (+), power consumption at 12V: 0.2A, 2.4W

scope of supply: 1 piece incl. 3 pin connector

Optional available:

replacement reflector: LED main headlight insert TYPE 4, chrome, Art.-ItemNo.: 226-018

Notes:

- Use asymmetrical, approved for right-hand traffic only.

- The enclosed 3-pole standard plug must be installed by the customer after reflector installation.

View of plug contacts:

Driving light (yellow) = right-hand

Dipped beam (blue) = top

ground (black) = left-hand

DIÁMETRO Ø (MM): 200
APPROVAL: CE APPROVAL
COMPOSITION: STEEL
COVER COLOR: TRANSLUCENT
PACKAGING: PER UNIT
COLOUR: CHROME
POSITION: FORWARD
LIGHT TYPE: LED
