Spark plug removal bit set M8/9/10/12 609.02.34

CONDOR Universal Glow Plug Boring Tool

To pierce spark plugs that are non-flashing or torn

Easy to use, fast and cost effective repair method

Also suitable for incandescent heaters

To drill out the glow plugs, remove the remaining glow plug and re-clip the wire

Specially adapted for glow plug size holes, sleeves, taps and tie bolts

All drills and taps in HSS-Co5 design - for a longer service life

Special socket wrench to remove the central electrode

Impact weight to remove debris from heater and 2 slide bars - to be used in case of space concerns

For almost all vehicle manufacturers

Scope of supply:

2x stop nut 14 mm hex

length 200mm

1x slide bar M10x1.5

Length 140mm

1x drill pitch ø 4.2x7x10 mm suitable for M8

1x drill hole ø 4.2x8x10 mm suitable for M9

1x drill hole ø 5x9x10 mm suitable for M10

1x drill hole ø 7x10.8x12 mm suitable for M12

1x thread cutter M5x0.8 suitable for M8, M9

1x thread cutter M6x1.0 suitable for M10

1x thread cutter M8x1.0 suitable for M8, M12

1x M9x1.0 thread cutter suitable for M9

1x thread cutter M10x1.0 suitable for M10

1x thread cutter M10x1.25 suitable for M10

1x M12x1.25 thread cutter suitable for M12

1x handle

Length 125mm

1x hole ø 2.5 mm suitable for M8, M9

1x hole ø 3.5 mm suitable for M10, M12

Length 120mm

1x tap-holder 1/4" drive

length 100mm

1x slide bar M10x1.5

Length 70mm

1x extension bolt M5x0.8 suitable for M8, M9

1x M6x1 extension bolt suitable for M10

1x M8x1 extension bolt suitable for M12

length 60mm

2x centering sleeve hole 2.5 mm suitable for M8, M9

length 50mm

1x Draw Bolt Adapter M8x1.25 x M10x1.5

1x weight 555g

length 40mm

2x 3.6 mm centering sleeve hole suitable for M10, M12

1x socket spanner 2.6mm 1/4" spiral groove profile

1x socket spanner 3.2mm 1/4" spiral groove profile

1x socket spanner 3.5mm 1/4" spiral groove profile

1x socket spanner 8.25mm 1/4" spiral groove profile
