ATHENA Forged Complete Piston Kit 95.97 MM C OFFROAD 756.22.31

Athena Offroad Piston Kits



Athena has developed a new line of "Offroad" piston kits for use on most 4-stroke offroad motorcycles.

Manufactured with special high-performance materials produced by reverse extrusion forging.



Special molybdenum disulfide coating sintered by screen printing process to improve flow/slide, performance and durability and reduce friction and noise.

State-of-the-art stainless steel segments with CrN PVD coating (chrome plating) and wear-resistant reinforcements whose shape has been optimized to improve formability under low tangential load.



Developed in Italy, the pistons undergo rigorous quality testing both on the dynamic bench and on the race track to ensure the highest levels of performance and reliability.



- High performance and flow/slip

- Reduced friction and noise

- Greater resistance and durability

- Stainless steel segments Made in Japan

- Wide range for most 4-stroke off-road motorcycles

- High quality at an affordable price.

Note:

PVD Coating: A process in which bombardment with laser beams, magnetically deflected ions or electrons, and arc discharge vaporize the so-called target material.
VERSION: STANDARD
PISTON DIAMETER: 95.97 MM
PISTON PIN: 19MM
QUALITY: FORGED
COMPRESSION RATIO: 1


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
SUZUKI RMX 450 Z 50/20 CV, 37/15 KW 1CIL. PL41A L0 BASTIDORES: PL41A-A2100001-- 2010-2013
COMPATIBLE WITHSUZUKI RMX 450 Z 50/20 CV, 37/15 KW 1CIL. PL41A L4 BASTIDORES: PL41A henceforth00500142-- 2014-2015
COMPATIBLE WITHSUZUKI RMX 450 Z 50/20 CV, 37/15 KW 1CIL. PL41A L6 BASTIDORES: PL41A henceforthG0100001-PL41A henceforthG0199999 2016
COMPATIBLE WITHSUZUKI RMX 450 Z 50/20 CV, 37/15 KW 1CIL. PL41A L7 BASTIDORES: PL41A henceforthH0100001-PL41A henceforthH0199999 2017
COMPATIBLE WITHSUZUKI RM-Z 450 57 CV, 42 KW 1CIL. RL42A K8 BASTIDORES: RL42A henceforth00500001-RL42A henceforth00503113 2008
COMPATIBLE WITHSUZUKI RM-Z 450 57 CV, 42 KW 1CIL. RL42A K9 BASTIDORES: RL42A henceforth00503114-RL42A henceforth00504912 2009
COMPATIBLE WITHSUZUKI RM-Z 450 57 CV, 42 KW 1CIL. RL42A L0 BASTIDORES: RL42A henceforth00504913-RL42A henceforth00506832 2010
COMPATIBLE WITHSUZUKI RM-Z 450 57 CV, 42 KW 1CIL. RL42A L1 BASTIDORES: RL42A henceforth00506833-RL42A henceforth00508584 2011
COMPATIBLE WITHSUZUKI RM-Z 450 57 CV, 42 KW 1CIL. RL42A L2 BASTIDORES: RL42A henceforth00508585-RL42A henceforth00509745 2012
