JT SPROCKETS Fine gear transmission pinion 17T 532 Ø24/28.5 726.49.22

The JT Sprockets production is today the largest and most modern production facility for sprockets and sprockets in the world.

equipped with the latest generation of CNC manufacturing machines.

JT Sprockets produces the full range of sprockets and sprockets for the original equipment and aftermarket.

Each pinion and sprocket goes through 25 production stages and undergoes more than ten individual quality tests to successfully leave production.

JT Sprockets manufactures the right way: turning, milling, and drilling. This is the only way to achieve the highest quality with the lowest tolerances and the best tooth profile.

After subsequent heat treatment, each element is checked by hand; this is how JT Sprockets sets new standards of quality in the motorcycle industry.
DIVISION: 532
CENTRAL FIXATION: FINE GEAR
INSIDE DIAMETER MIN.: 24 MM
MAX INTERNAL DIAMETER: 28.7 MM
INNER GEAR (QUANTITY OF TEETH): 12
QUANTITY OF HOLES: WITHOUT HOLE
VERSION: STANDARD
QTY TEETH: 17


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Kawasaki ZX-10 1000 B Tomcat 100 CV, 74 kw 4cil. ZXT00B 1 Bastidores: ZXT00B henceforth00001-ZXT00B henceforth12000 1988
Kawasaki ZX-10 1000 B Tomcat 100 CV, 74 kw 4cil. ZXT00B 1 Bastidores: ZXT00B henceforth12452-ZXT00B henceforth17000 1988
Kawasaki ZX-10 1000 B Tomcat 100 CV, 74 kw 4cil. ZXT00B 2 Bastidores: ZXT00B henceforth12001-ZXT00B henceforth12451 1989
Kawasaki ZX-10 1000 B Tomcat 100 CV, 74 kw 4cil. ZXT00B 2 Bastidores: ZXT00B henceforth17001-ZXT00B henceforth28000 1989
Kawasaki ZX-10 1000 B Tomcat 100 CV, 74 kw 4cil. ZXT00B 3 Bastidores: ZXT00B henceforth28001-ZXT00B-999999 1990
