ESJOT Fine gear transmission pinion 13T 420 Ø14/16.5 726.41.79

ESJOT gear designed specifically for high OEM requirements and among the world's best sprockets on the market.

A special steel, high-quality hardening and optimum gearing guarantee extremely high strength and durability - ideal for high-wear conditions in all areas

- Steel 16 MnCR 5

- Worked on CNC lathes

- Hardening of 700 HV 40 for a depth of 0.4 mm

- Modern broaching guarantees an exact fit size on the motor shaft

- Radial and axial runout tolerance of less than 0.1mm

- 100% Made in Germany

- OEM quality
DIVISION: 420
CENTRAL FIXATION: FINE GEAR
INSIDE DIAMETER MIN.: 14 MM
MAX INSIDE DIAMETER: 16.5 MM
INNER GEAR (QUANTITY OF TEETH): 10
QUANTITY OF HOLES: WITHOUT HOLE
WIDTH: 12MM
VERSION: STANDARD
QTY TEETH: 13


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Gilera GSM 50 2,9 CV, 2,1 kw 1cil. VTBC33200 Bastidores: VTBC33200 henceforth0001001-- 2002-2003
