ESJOT Fine gear transmission pinion 17T 520 Ø21.4/25 726.28.35

ESJOT sprocket has been specifically developed to meet OEM requirements and is among the world's best sprockets on the market.

A special steel, high-quality hardening and precise teeth provide extremely high strength and durability - ideal for wear-intensive conditions in all areas

- Steel 16 MnCR 5

- worked on CNC lathes

- hardening of 700 HV 40, for a depth of 0.4 mm

- modern broaching ensure a precise fit size on the motor shaft

- radial and axial run-out tolerance of less than 0.1 mm

- 100% Made in Germany

- OEM quality
DIVISION: 520
CENTRAL FIXATION: FINE GEAR
INSIDE DIAMETER MIN.: 18 MM
MAX INSIDE DIAMETER: 20 MM
INNER GEAR (QUANTITY OF TEETH): 19
QUANTITY OF HOLES: WITHOUT HOLE
WIDTH: 37MM
VERSION: STANDARD
QTY TEETH: 17


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Aeon Cobra 125 RS 2WD 5,4 CV, 4 kw 1cil. - AT72 Bastidores: --- 2003-2006
Aeon Cobra 180 RS 2WD 8,4 CV, 6,2 kw 1cil. - Bastidores: --- 2002-2003
Aeon Overland 180 2WD 8,4 CV, 6,2 kw 1cil. - Bastidores: --- 2002-2003
