ATHENA motorcycle cylinder kit 240CCM BIG BORE 756.08.60

Athena cylinder set

For more than 10 years, Athena has been investing in the best and most modern technologies for the manufacture of cylinders and their components, which are used not only by original equipment manufacturers, but also by the best racing teams in the world.

Last but not least, the production of aluminum cylinders is constantly improving through cooperation with the best Italian universities, as well as constant requests for further development from the best engine tuners.

Thanks to a flexible production department, Athena can react efficiently to different situations (original equipment manufacturer production batches, small quantities, building a prototype for racing teams).

Athena cylinders are made of high quality aluminum alloys. They are manufactured taking into account the latest technologies and coated with a nickel-silicon alloy. After all cylinders have gone through rigorous quality checks, they meet the highest standards in terms of reliability, durability and performance.

Technical specifications:

Cylinder material: Aluminum

Cooling type: water cooled

Diameter: 67mm.

Stroke: 66.21mm

Displacement: 233.4cc

Compression: 11.9:1

Piston Pin Diameter: 15mm.

Stock: not included in the scope of delivery

Maximum performance at the crankshaft: 21 hp / 8000 rpm


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Honda CRF 230 F 19 CV, 14 kw 1cil. ME09 7 Bastidores: 9C2 ME099-7R900001-9C2 ME099-7R999999 2007
Honda CRF 230 F 19 CV, 14 kw 1cil. ME09A 8 Bastidores: 9C2 ME09A-8R900001-9C2 ME09A-8R999999 2008
Honda CRF 230 F 19 CV, 14 kw 1cil. ME09A 9 Bastidores: 9C2 ME09A-9R900001-- 2009
