JMP Water radiator with damping rubber 776.01.74

JMP water cooler

>>> Optimum cooling performance and durability <<<<

JMP Advantages:

- Better cooling performance thanks to special fin technology

- Ideal for motors with high thermal loads

- Hand welded, polished and pressure tested

- Can be swapped directly for the original equipment radiator

When the engine is running, friction and heat are automatically generated. Therefore, the motor must be cooled in the best possible way to avoid overheating.

Water coolers are made up of tubes with fins between them. Coolant flows through these tubes. A continuous flow of air cools the fluid and thus prevents the motor from overheating.

Variants of the water cooler:

- Radiator mechanically clogged

- Brazed radiator

Mechanically Plugged Cooler:

- Production that saves costs and energy

- Round tubes fully inserted through the fins

- Less air space between tubes and fins

- Lower heat transfer / cooling capacity

Brazed Fin Cooler:

- Tubes and fins are welded in the furnace

- Creation of a metallic joint

- Optimum heat transfer

- Flattened tubes

- Larger cooling surface

- Up to 60% more cooling capacity


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Yamaha XP 500 A TMax ABS 46,5 CV, 34,2 kw 2cil. SJ092 59C2 Bastidores: SJ092 henceforth00301-- 2012
Yamaha XP 500 A TMax ABS 46,5 CV, 34,2 kw 2cil. SJ092 59C9 Bastidores: SJ092 henceforth09046-- 2013
Yamaha XP 500 A TMax ABS 46,5 CV, 34,2 kw 2cil. SJ092 59CN Bastidores: SJ092 henceforth21826-- 2014
Yamaha XP 500 A TMax Black Max ABS 46,5 CV, 34,2 kw 2cil. SJ092 59CE Bastidores: SJ092 henceforth11476-- 2013
Yamaha XP 500 A TMax Bronze Max ABS 46,5 CV, 34,2 kw 2cil. SJ092 59CT Bastidores: SJ092 henceforth22415-- 2014
Yamaha XP 500 TMax 46,5 CV, 34,2 kw 2cil. SJ091 59C1 Bastidores: SJ091 henceforth00301-- 2012
Yamaha XP 500 TMax 46,5 CV, 34,2 kw 2cil. SJ091 59C8 Bastidores: SJ091 henceforth11776-- 2013
Yamaha XP 500 TMax 46,5 CV, 34,2 kw 2cil. SJ091 59CM Bastidores: SJ091 henceforth18530-- 2014
Yamaha XP 500 TMax Black Max 46,5 CV, 34,2 kw 2cil. SJ091 59CF Bastidores: SJ091 henceforth13212-- 2013
Yamaha XP 500 TMax Bronze Max 46,5 CV, 34,2 kw 2cil. SJ091 59CS Bastidores: SJ091 henceforth18703-- 2014
