JMP Water radiator 776.01.41

JMP water cooler

>>> Optimum cooling performance and durability <<<<

JMP Advantages:

- Better cooling performance thanks to special fin technology

- Ideal for motors with high thermal loads

- Hand welded, polished and pressure tested

- Can be swapped directly for the original equipment radiator

When the engine is running, friction and heat are automatically generated. Therefore, the motor must be cooled in the best possible way to avoid overheating.

Water coolers are made up of tubes with fins between them. Coolant flows through these tubes. A continuous flow of air cools the fluid and thus prevents the motor from overheating.

Variants of the water cooler:

- Radiator mechanically clogged

- Brazed radiator

Mechanically Plugged Cooler:

- Production that saves costs and energy

- Round tubes fully inserted through the fins

- Less air space between tubes and fins

- Lower heat transfer / cooling capacity

Brazed Fin Cooler:

- Tubes and fins are welded in the furnace

- Creation of a metallic joint

- Optimum heat transfer

- Flattened tubes

- Larger cooling surface

- Up to 60% more cooling capacity


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Ducati 1098 1098 Biposto/Monoposto 160 CV, 119 kw 2cil. H700AA/H701AA Bastidores: --- 2007-2008
Ducati 1098 1098 S Biposto/Monoposto 160 CV, 119 kw 2cil. H700AA/H701AA Bastidores: --- 2007-2008
Ducati 1098 1198 R 180 CV, 132 kw 2cil. H702AB/H703AB Bastidores: --- 2008-2009
Ducati 1198 1198 170 CV, 125 kw 2cil. H704AA/H705AA Bastidores: --- 2009-2011
Ducati 1198 1198 R Corse 180 CV, 132 kw 2cil. H702AB/H703AB Bastidores: --- 2010
Ducati 1198 1198 S 170 CV, 125 kw 2cil. H704AA/H705AA Bastidores: --- 2009-2010
Ducati 1198 1198 S Corse 170 CV, 125 kw 2cil. H704AA/H705AA Bastidores: --- 2010
Ducati 1198 1198 SP 170 CV, 125 kw 2cil. H704AA/H705AA Bastidores: --- 2011
Ducati 848 848 134 CV, 99 kw 2cil. H600AA/H601AA Bastidores: --- 2008-2010
Ducati 848 848 Evo 140 CV, 103 kw 2cil. H602AA/H603AA Bastidores: --- 2011-2013
Ducati 848 848 Evo Corse SE 140 CV, 103 kw 2cil. H602AA/H603AA Bastidores: --- 2012-2013
Ducati 848 848 Evo Dark 140 CV, 103 kw 2cil. H602AA/H603AA Bastidores: --- 2011-2013
Ducati XDiavel 1260 S ABS 152 CV, 112 kw 2cil. 13BKW0/WX/GA00AA/GA01JA/GB00FA Bastidores: --- 2017
