MITSUBOSHI BELT, DRIVE, TRANSMISSION MI093

MITSUBOSHI Belting, Ltd. "Belts that transmit power" is the motto of this Japanese colossus, a producer of belts since 1919, faithfully committed to their development.

Your product is positioned at the highest range, whether they are traditional, reinforced or double toothed belts.

Reliability and quality make manufacturers such as Yamaha, Suzuki and Piaggio choose Mitsuboshi as their original equipment supplier.

The traditional trapezoidal belt and the double-toothed belt are made of thread and rubber, reinforced with an ARAMID FIBER insert.

The fiber is mixed with the rubber, along the length of the belt, to contribute to a correct transmission of power and at the same time increase resistance to overheating and abrasion.

The serration reduces the stress caused by tensile flexing and heat build-up. The lateral cut allows an excellent seating of the belt on the transmission pulley.

The braiding is particularly resistant to eventual loads at certain points of the belt. Its interlocking reinforcement on the inside and outside of the belt increases the traction stability of the vehicle.

Thanks to an optimal contact surface, and unprecedented adhesion, Mitsuboshi belts guarantee power transmission efficiency that translates into ACCELERATION, RESPONSE and SILENCE.
LENGTH (MM): 995
WIDTH (MM): 24.1
HEIGHT (MM): 11.4
ANGLE (°): 32
OEM REFERENCES: 127543
13525520
23100KTW901
23100LLJ3900
23100LLJ3E00
COMPOSITION: ARAMIDE
STRAP QUALITY: STANDARD


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this item is compatible with the following makes, models and years:
COMPATIBLE WITH HONDA FORZA 300 300 2015-2021
COMPATIBLE WITH HONDA SH 300 ABS (NF05) 300 2015-2019
COMPATIBLE WITH HONDA SH 300 S ABS (NF05) 300 2017
COMPATIBLE WITH HONDA SH 300I 300 2020
COMPATIBLE WITH KYMCO PEOPLE 250 LC 250 2003-2005
COMPATIBLE WITH KYMCO PEOPLE 250 S 250 2006-2008
COMPATIBLE WITH KYMCO PEOPLE 300I S 300 2008-2010
COMPATIBLE WITH KYMCO X CITING 250 250 2005-2008
COMPATIBLE WITH KYMCO X-TOWN 300 ABS 300 2016-2020
