MITSUBOSHI BELT, DRIVE, TRANSMISSION MI050

MITSUBOSHI Belting, Ltd. "Belts that transmit power" is the motto of this Japanese colossus, a producer of belts since 1919, faithfully committed to their development.

Your product is positioned at the highest range, whether they are traditional, reinforced or double toothed belts.

Reliability and quality make manufacturers such as Yamaha, Suzuki and Piaggio choose Mitsuboshi as their original equipment supplier.

The traditional trapezoidal belt and the double-toothed belt are made of thread and rubber, reinforced with an ARAMID FIBER insert.

The fiber is mixed with the rubber, along the length of the belt, to contribute to a correct transmission of power and at the same time increase resistance to overheating and abrasion.

The serration reduces the stress caused by tensile flexing and heat build-up. The lateral cut allows an excellent seating of the belt on the transmission pulley.

The braiding is particularly resistant to eventual loads at certain points of the belt. Its interlocking reinforcement on the inside and outside of the belt increases the traction stability of the vehicle.

Thanks to an optimal contact surface, and unprecedented adhesion, Mitsuboshi belts guarantee power transmission efficiency that translates into ACCELERATION, RESPONSE and SILENCE.
LENGTH (MM): 848
WIDTH (MM): 18.1
HEIGHT (MM): 8
ANGLE ( ° ): 30
OEM REFERENCES: 210825059
484758
800093625
825059
8550363
COMPOSITION: POLYESTER
STRAP QUALITY: STANDARD


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this item is compatible with the following makes, models and years:
COMPATIBLE WITH APRILIA HABANA 125 CUSTOM 125 1999-2002
COMPATIBLE WITH APRILIA HABANA 125 RETRO 125 1999-2002
COMPATIBLE WITH APRILIA MOJITO 125 CUSTOM 125 1999-2002
COMPATIBLE WITH APRILIA MOJITO 125 RETRO 125 1999-2002
COMPATIBLE WITH CAGIVA CUCCIOLO 125 125 2000-2000
COMPATIBLE WITH CAGIVA CUCCIOLO 125 125 2002-2003
COMPATIBLE WITH ITALJET TORPEDO 125 125 1998-2011
COMPATIBLE WITH PIAGGIO HEXAGON 125 4T LX4 (M150) 125 1998-2000
COMPATIBLE WITH PIAGGIO LIBERTY 125 125 1998-2000
