MITSUBOSHI BELT, DRIVE, TRANSMISSION MI101

MITSUBOSHI Belting, Ltd. "Belts that transmit power" is the motto of this Japanese colossus, a producer of belts since 1919, faithfully committed to their development.

Your product is positioned at the highest range, whether they are traditional, reinforced or double toothed belts.

Reliability and quality make manufacturers such as Yamaha, Suzuki and Piaggio choose Mitsuboshi as their original equipment supplier.

The traditional trapezoidal belt and the double-toothed belt are made of thread and rubber, reinforced with an ARAMID FIBER insert.

The fiber is mixed with the rubber, along the length of the belt, to contribute to a correct transmission of power and at the same time increase resistance to overheating and abrasion.

The serration reduces the stress caused by tensile flexing and heat build-up. The lateral cut allows an excellent seating of the belt on the transmission pulley.

The braiding is particularly resistant to eventual loads at certain points of the belt. Its interlocking reinforcement on the inside and outside of the belt increases the traction stability of the vehicle.

Thanks to an optimal contact surface, and unprecedented adhesion, Mitsuboshi belts guarantee power transmission efficiency that translates into ACCELERATION, RESPONSE and SILENCE.
LENGTH (MM): 939
WIDTH (MM): 22
ALTURA (MM): 13
ÁNGULO ( ° ): 28
OEM REFERENCES: 828043
842011
8575041
COMPOSITION: ARAMIDE
STRAP QUALITY: STANDARD


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this item is compatible with the following makes, models and years:
COMPATIBLE WITH APRILIA SCARABEO 200 GT 200 2002-2006
COMPATIBLE WITH APRILIA SCARABEO 200 STREET 200 2003-2007
COMPATIBLE WITH APRILIA SPORTCITY 200 200 2004-2008
COMPATIBLE WITH PIAGGIO BEVERLY 200 (M282) 200 2002-2004
COMPATIBLE WITH PIAGGIO CARNABY 200 E3 (M601) 200 2007-2008
