YSS SUSPENSION Linear clevis springs 8.5 743.04.66

YSS linear fork springs with a firmer design than the original.

YSS fork springs are made of high quality silicon spring steel. This allows the thickness of the wire to be reduced, which makes the spring more active and thinner, but at the same time effectively prevents twisting of the spring.

To minimize noise and improve oil flow in the fork, the springs are fully polished and ground on the top and bottom.

The scope of delivery includes 2 springs for a complete conversion of the fork.
SPRING TYPE: LINEAR
Length: 270mm
DIAMETER 1: 36MM
DIAMETER 2: 24MM
HARDNESS 1: 8.5 N/MM
LEFT AIR CHAMBER: 100-115 MM
RIGHT AIR CHAMBER: 100-115 MM
RECOMMENDED VISCOSITY: 10W


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Suzuki GSX-R 600 125 CV, 92 kw 4cil. C31111 L1 Bastidores: C31111 henceforth0100001-C31111 henceforth0103028 2011
Suzuki GSX-R 600 125 CV, 92 kw 4cil. C31111 L2 Bastidores: C31111 henceforth0103029-C31111 henceforth0103223 2012
Suzuki GSX-R 600 125 CV, 92 kw 4cil. C31111 L3 Bastidores: C31111 henceforth0103224-C31111 henceforth0103520 2013
Suzuki GSX-R 600 125 CV, 92 kw 4cil. C31111 L4 Bastidores: C31111 henceforth0103521-C31111 henceforth0103951 2014
Suzuki GSX-R 600 125 CV, 92 kw 4cil. C31111 L5 Bastidores: C31111 henceforth0103952-C31111 henceforth0109999 2015
Suzuki GSX-R 600 126 CV, 92,5 kw 4cil. C31111 L6 Bastidores: C31111-G0100001-C31111-G0109999 2016
Suzuki GSX-R 600 126 CV, 92,5 kw 4cil. C31111 L7 Bastidores: C31111-H0100001-C31111-H0109999 2017
Suzuki GSX-R 600 30th Anniversary 126 CV, 92,5 kw 4cil. C31111 L6 Bastidores: C31111-G0100001-C31111-G0109999 2016
Suzuki GSX-R 600 UE 34 CV, 25 kw 4cil. C33111 L1 Bastidores: C33111 henceforth0100001-C33111 henceforth0100100 2011
Suzuki GSX-R 600 UE 34 CV, 25 kw 4cil. C33111 L2 Bastidores: C33111 henceforth0100101-- 2012
Suzuki GSX-R 600 UE 34 CV, 25 kw 4cil. C33111 L3 Bastidores: C33111 henceforth0100101-- 2013
Suzuki GSX-R 600 UF 106 CV 78 kw 4cil. C32111 L1 Bastidores: C32111 henceforth0100001-C32111 henceforth0100455 2011
Suzuki GSX-R 600 UF 106 CV 78 kw 4cil. C32111 L2 Bastidores: C32111 henceforth0100456-C32111 henceforth0100535 2012
Suzuki GSX-R 600 UF 106 CV 78 kw 4cil. C32111 L3 Bastidores: C32111 henceforth0100536-C32111 henceforth0100565 2013
Suzuki GSX-R 600 UF 106 CV 78 kw 4cil. C32111 L4 Bastidores: C32111 henceforth0100566-C32111 henceforth0100653 2014
Suzuki GSX-R 600 UF 106 CV 78 kw 4cil. C32111 L5 Bastidores: C32111 henceforth0100654-C32111 henceforth0109999 2015
Suzuki GSX-R 600 UF 106 CV 78 kw 4cil. C32111 L6 Bastidores: C32111-G0100001-C32111-G0109999 2016
Suzuki GSX-R 600 UF Anniversary 106 CV 78 kw 4cil. C32111 L6 Bastidores: C32111-G0100001-C32111-G0109999 2016
