YSS SUSPENSION TDS Adjustable Mono Shock Absorber 7431074

YSS TDS shock absorber - developed by the YSS competition department
The YSS TDS damper was developed by the in-house racing department specifically for track use. It is aimed at professional racers and ambitious track day riders who demand the highest standards of performance, precision, and adjustability.
Outstanding features:
- High-quality gas pressure shock absorber with precisely adjustable damping
- Infinitely adjustable spring preload - for precise adjustment to rider weight and track conditions
- Robust CNC-milled aluminum construction - lightweight, stable, and durable
- External reservoir - ensures consistent damping performance even under extreme loads
- Rebound adjustment - for precise control of rebound behavior
- Compression adjustment - separately adjustable for high and low speed
- Vehicle-specific design - easy installation without additional adjustments
The YSS TDS damper allows you to precisely adjust the suspension to suit the track, temperature, and driving style. The result: maximum traction, optimal driving stability, and direct, responsive handling, even under the most demanding racing conditions.
Note:
- The spring preload can be adjusted hydraulically on a continuous basis.
- Rebound adjustment 30 clicks - Compression adjustment (high/low 30 clicks) - The expansion reservoir offers better temperature control, consistent damping and higher working pressure.
- The length of the shock absorber is adjustable by +-5mm
TYPE: GAS PRESSURE
UPPER FIXATION: EYE
INNER EYE DIAMETER: 12 MM
LENGTH: 360-370 MM
LOWER FIXATION: EYE
INNER EYE DIAMETER: 12 MM
ADJUSTMENTS: PRESSURE LEVEL WITH HIGH/LOW ADJUSTMENT, HYDRAULIC SPRING PRELOAD, LENGTH ADJUSTMENT +/- 5 MM, TRACTION LEVEL
SPRING CHARACTERISTIC: 55
SPRING LENGTH: 185 MM
SPRING DIAMETER: 56 MM
COMPENSATION DEPOSIT: YES
PISTON DIAMETER: 45 MM
PISTON ROD DIAMETER: 16 MM
SPRING TYPE: LINEAR
LENGTH: 320MM
DIAMETER 1: 30.3 MM
HARDNESS 1: 8.5 N/MM
RECOMMENDED VISCOSITY: 5W


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this item is compatible with the following makes, models and years:
COMPATIBLE WITH BMW S 1000 RR ABS 2019
COMPATIBLE WITH BMW S 1000 RR ABS DTC 2020-2021
COMPATIBLE WITH BMW S 1000 RR ABS DTC DDC 2020-2021
COMPATIBLE WITH BMW S 1000 RR ABS DTC M-Paket 2020
COMPATIBLE WITH BMW S 1000 RR ABS DTC Race-Paket 2020-2021
COMPATIBLE WITH BMW S 1000 RR ABS M-paquete 2019
COMPATIBLE WITH BMW S 1000 RR ABS paquete dinámico 2019
COMPATIBLE WITH BMW S 1000 RR ABS Race-paquete 2019
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC Carbonrad 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC Dynamik Paket 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC Dynamik Paket Carbonrad 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC Dynamik Paket Schmiederad 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC M-Paket Carbonrad 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC M-Paket Schmiederad 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC Race-Paket 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC Race-Paket Carbonrad 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC Race-Paket Schmiederad 2022
COMPATIBLE WITH BMW S 1000 RR Bis 082022 ABS DTC Schmiederad 2022
