YSS SUSPENSION Adjustable mono shock absorber for motorcycle 7892253

Milled aluminum body, adjustable spring preload and rebound shock (30 clicks).

The spring preload is locked by a set screw.

The adjustment tool is included in the scope of delivery.
TYPE: GAS PRESSURE
UPPER FIXATION: EYE
INNER EYE DIAMETER: 10 MM
LENGTH: 375MM
LOWER FIXATION: EYE
INNER EYE DIAMETER: 20 MM
ADJUSTMENTS: VARIABLE SPRING PRELOAD
SPRING FEATURE: 180
SPRING LENGTH: 215 MM
SPRING DIAMETER: 56 MM
COMPENSATION DEPOSIT: NO
PISTON DIAMETER: 45 MM
PISTON ROD DIAMETER: 16 MM


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Triumph Tiger Explorer 1200 ABS 137 CV, 101 kw 3cil. V13VG Bastidores: --740276 2016
COMPATIBLE WITHTriumph Tiger Explorer 1200 ABS 137 CV, 101 kw 3cil. V13VG Bastidores: SMTV1F11E9 --SMTV1F11E9 - 740276 2012-2015
COMPATIBLE WITHTriumph Tiger Explorer 1200 ABS 98 CV, 72 kw 3cil. V13VG Bastidores: SMTV1F11E9 --SMTV1F11E9 - 740276 2012-2015
COMPATIBLE WITHTriumph Tiger Explorer 1200 ABS llanta de radios 137 CV, 101 kw 3cil. V13VG Bastidores: --740276 2016
