YSS SUSPENSION Adjustable rear double suspension shock absorber 789.22.99

Milled aluminum body, adjustable spring preload and rebound shock (30 clicks).

The spring preload is locked by a pressure screw.

The length of the damper is adjustable by +-5mm.

The adjustment tool is included in the scope of delivery.
TYPE: GAS PRESSURE
UPPER FIXATION: EYE
INNER EYE DIAMETER: 10 MM
LENGTH: 315MM
LOWER FIXATION: EYE
INNER EYE DIAMETER: 10 MM
ADJUSTMENTS: VARIABLE SPRING PRELOAD
SPRING CHARACTERISTIC: 17-25
SPRING LENGTH: 200 MM
SPRING DIAMETER: 46 MM
COMPENSATION DEPOSIT: NO
PISTON DIAMETER: 30 MM
PISTON ROD DIAMETER: 12 MM


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Royal Enfield Bullet 500 EFI Deluxe asiento de banqueta 27,6 CV, 20,3 kw 1cil. - Bastidores: --- 2009-2014
Royal Enfield Bullet 500 EFI Electra asiento de banqueta 27,6 CV, 20,3 kw 1cil. - Bastidores: --- 2010-2014
Royal Enfield Bullet 500 EFI Standard ABS asiento de banqueta 27,2 CV, 20 kw 1cil. - Bastidores: --- 2017-2018
Royal Enfield Bullet 500 EFI Standard asiento de banqueta 27,6 CV, 20,3 kw 1cil. - Bastidores: --- 2011-2016
Royal Enfield Classic 500 EFI ABS monoplaza 27,2 CV, 20 kw 1cil. - Bastidores: --- 2017-2018
Royal Enfield Classic 500 EFI Chrom ABS monoplaza 27,2 CV, 20 kw 1cil. - Bastidores: --- 2017-2018
Royal Enfield Classic 500 EFI Chrom monoplaza 27,6 CV, 20,3 kw 1cil. - Bastidores: --- 2011-2016
Royal Enfield Classic 500 EFI Desert Storm ABS monoplaza 27,2 CV, 20 kw 1cil. - Bastidores: --- 2017-2018
Royal Enfield Classic 500 EFI Desert Storm monoplaza 27,6 CV, 20,3 kw 1cil. - Bastidores: --- 2012-2016
Royal Enfield Classic 500 EFI Military Battle Green ABS monoplaza 27,2 CV, 20 kw 1cil. - Bastidores: --- 2017-2018
Royal Enfield Classic 500 EFI Military Battle Green monoplaza 27,6 CV, 20,3 kw 1cil. - Bastidores: --- 2012-2016
Royal Enfield Classic 500 EFI monoplaza 27,6 CV, 20,3 kw 1cil. - Bastidores: --- 2009-2016
Royal Enfield Classic 500 EFI Redditch Edition ABS 27,2 CV, 20 kw 1cil. - Bastidores: --- 2018
