YSS SUSPENSION Adjustable rear double suspension shock absorber 789.07.05

Oil pressure shock absorber with steel housing, spring preload adjustable in 5 locking points.



Adjustment tool included.
TYPE: OIL PRESSURE
UPPER FIXATION: EYE
INNER EYE DIAMETER: 12 MM
LENGTH: 330MM
LOWER FIXATION: EYE
INNER EYE DIAMETER: 12 MM
ADJUSTMENTS: SPRING PRELOAD
SPRING CHARACTERISTIC: 17-25
SPRING LENGTH: 200 MM
SPRING DIAMETER: 46 MM
COMPENSATION DEPOSIT: NO
PISTON DIAMETER: 22 MM
PISTON ROD DIAMETER: 12 MM


APPLICATIONS OF THIS PRODUCT:
According to the data provided by the manufacturer, this article is compatible with the following brands, models and years:
Laverda Alpino 350 30 CV, 22 kw 2cil. - Bastidores: --- 1978-1982
Suzuki GN 400 L llanta de fundición 27/17 CV, 20/13 kw 1cil. GN400 X Bastidores: GN400-506771-- 1981-1982
Suzuki GN 400 TD llanta de radios 27 CV, 20 kw 1cil. GN400 T Bastidores: GN400-100001-GN400-108208 1980
Suzuki GN 400 TD llanta de radios 27/17 CV, 20/13 kw 1cil. GN400 X Bastidores: GN400-108209-- 1981-1982
Suzuki GS 450 L 27 CV, 20 kw 2cil. GL51D F Bastidores: GL51D-100305-GL51D-100706 1985
Suzuki GS 450 L 27 CV, 20 kw 2cil. GL51D G Bastidores: GL51D-100707-GL51D-101250 1986
Suzuki GS 450 L 27 CV, 20 kw 2cil. GL51D H Bastidores: GL51D-101251-- 1987
Suzuki GS 450 L 42 CV, 31 kw 2cil. GL51D F Bastidores: GL51D-100305-GL51D-100706 1985
Suzuki GS 450 L 42 CV, 31 kw 2cil. GL51D G Bastidores: GL51D-100707-GL51D-101250 1986
Suzuki GS 450 L 42 CV, 31 kw 2cil. GL51D H Bastidores: GL51D-101251-- 1987
Suzuki GS 450 T 42 CV, 31 kw 2cil. GS450 X Bastidores: GS450-800001-- 1981-1983
Suzuki GS 450 TU 27 CV, 20 kw 2cil. GS450U X Bastidores: GS450U-800001-- 1981-1983
Suzuki GS 500 E 27 CV, 20 kw 4cil. GS500E N Bastidores: GS500E-102081-- 1979
Suzuki GS 550 L llanta de fundición 49 CV, 36 kw 4cil. GS550E T Bastidores: GS550E-705236-- 1980
Suzuki GS 550 M Katana 50 CV, 37 kw 4cil. GS550M X Bastidores: GS550M-100001-GS550M-105958 1981-1983
Suzuki GS 550 M Katana anti dive 50 CV, 37 kw 4cil. GS550M Z Bastidores: GS550M-105959-- 1982-1983
Suzuki GSX 250 27 CV, 20 kw 2cil. GS25X T Bastidores: GS25X-100001-GS25X-110047 1980
Suzuki GSX 250 27 CV, 20 kw 2cil. GS25X X Bastidores: GS25X-110048-- 1981
Suzuki GSX 250 U 17 CV, 13 kw 2cil. GS25X T Bastidores: GS25X-100001-GS25X-110047 1980
Suzuki GSX 250 U 17 CV, 13 kw 2cil. GS25X X Bastidores: GS25X-110048-- 1981
