MAGURA hydraulic clutch pump HYMEC 729.02.47

MAGURA HYDRAULIC STREET CLUTCH CYLINDER 167

Aluminum hydraulic clutch master cylinder with cast container,

Forged aluminum lever, switch and mirror clamp mounted.

Easily adjustable lever position via optimized knurled screw, easy installation

This docking unit is only suitable for street models. It has a longer, bent lever that fits around the electrical switch unit.

- for the use of mineral oil

- Leverage 1: 4

- Connection thread M10x1

- piston diameter 10.5 mm (sports operation)

-Length: 163 mm black

- Maximum stroke of the slave cylinder: 10-12 mm.

With this master cylinder and the corresponding accessories, an individual hydraulic clutch can be assembled for almost any vehicle.

Required Accessories:

Shortenable 1500 mm pressure line.

Hollow screw with vent

Services / Befüllset

- Mount the hydraulic slave cylinder to measure the length.
