KUKKO SPLITTER 5-60 MM 646.00.05

KUKKO® spreading device with quick pressure spindle, 17 series

For removal of ball bearings, roller bearings, inner rings and other flush sitting parts

An indispensable tool for automotive, agricultural and industrial mechanic removal.

Particularly practical because the spreader jaws are clamped quickly and centrally with a quick pressure spindle

Sharp edges make the support parts flush with stripping where hooks are inapplicable

Large contact areas protect the deducted part

The sharp wedge-shaped blades are pressed behind the parts to be disassembled and sat between the bearing and the seat

To remove the puller series loop bolt must be 18 (only applicable in combination with this - see accessories) is screwed into the separating device

Caution: Detail image for promotional use only! Observe the safety instructions!

Ø Gap: 5 -60 mm (13/64 / 2 3/8 ")

standoff bolt distance: 60mm (2 3/8")

Diameter: M10

Weight: 0.95kg
TYPE: EXTERNAL EXTRACTOR
INTENDED USE: BEARINGS / BEARINGS
DRIVE: EXTERNAL HEXAGON
